Viridian Clearline Inverter - Solar Inverter 3.0kW with Integrated DC Isolator Switch - Single MPPT

Viridian Clearline Inverter - Solar Inverter 3.0kW with Integrated DC Isolator Switch - Single MPPT is a compact, high-efficiency solar inverter tailored for UK residential photovoltaic installations up to 6 kWp. Designed to meet the needs of installers seeking a quick, reliable, and regulation-compliant system, it features a peak conversion efficiency of 97.6% and silent operation with no moving parts.

Weighing just 4.6 kg and occupying an A4-sized footprint (306 × 218 × 119 mm), this 3kW single-phase inverter is quick to install by a single technician. A factory-fitted rotary DC isolator ensures BS 7671 compliance, while a 16 A single MPPT input supports wide voltage ranges (40–550 V) for optimal energy harvesting across changing conditions.

The IP66-rated aluminium enclosure allows for both indoor and outdoor mounting, and optional smart connectivity enables real-time monitoring, firmware updates, and export-limitation features via the Viridian app (Wi-Fi/LAN module required).

Key Features and Benefits:

• 3,000 W AC nominal output – Suitable for PV systems up to 6 kWp
• High efficiency – 97.6% peak efficiency for maximum solar yield
• Integrated DC isolator – Factory-fitted rotary switch compliant with BS 7671
• Single MPPT design – One 16 A tracker with 40–550 V input range
• Silent operation – Passive, fan-less cooling keeps noise levels under 20 dB
• Weatherproof housing – Lightweight IP66-rated aluminium chassis
• Quick install – Plug-and-play AC connector and MC4 DC inputs
• Low standby consumption – Under 3 W for minimal energy loss
• Advanced protections – PV insulation resistance detection, residual current monitoring, AC/DC surge protection, anti-islanding
• UK-based support and 10-year warranty – Next-day spares and design assistance from Viridian’s Cambridge team

Technical Specifications:

Download the datasheet for Viridian Clearline Inverter - Solar Inverter 3.0kW with Integrated DC Isolator Switch - Single MPPT here

For technical support or additional information, reach out to us at hello@offgridrenewables.co.uk.
