Sungrow SBS 5.0kWh High Voltage Battery Module
Sungrow SBS 5.0kWh High Voltage Battery Module
Couldn't load pickup availability
SKU:SBS050
Sungrow SBS 5.0kWh High Voltage Battery Module (ASA00460)
The Sungrow SBS 5.0kWh High Voltage Battery Module (ASA00460) is a modular energy storage solution designed for residential solar energy systems. Utilising advanced LiFePO₄ prismatic cells, this battery module offers exceptional safety, efficiency, and long-term durability. Its compact and versatile design allows for both indoor and outdoor installations, providing flexibility for various residential setups.
As part of the SBS Battery System, this module is not a standalone product but is designed to be stacked in configurations ranging from 1 to 4 modules, delivering a scalable capacity from 5.12 kWh up to 20.48 kWh. The system's refined battery management and plug-and-play design eliminate the need for a junction box during expansion, simplifying installation and maintenance.
Technical Specifications
| General Information | |
|---|---|
| Brand | Sungrow |
| Model | ASA00460 |
| Battery Type | LiFePO₄ Prismatic Cell |
| Nominal Capacity | 5.0 kWh |
| Usable Capacity | 5.0 kWh (100%) |
| Nominal Voltage | 102.4 V |
| Charge/Discharge Current | 50 A |
| Communication Interface | CAN |
| Degree of Protection | IP55 |
| Dimensions (W x H x D) | 515 x 780 x 182 mm |
| Weight | 58 kg |
| Installation Environment | Indoor and Outdoor |
| Scalability | 1 to 4 modules (5.12 kWh to 20.48 kWh) |
| Grid Connection | Grid and Off-Grid Capable |
Download the datasheet for Sungrow SBS 5.0kWh High Voltage Battery Module here: Sungrow SBS 5.0kWh Datasheet
For technical support or additional information, reach out to us at hello@offgridrenewables.co.uk.
