Schletter Seam Clamp 504 AL KK for Standing Seam Roof – 112001-010
The Schletter Seam Clamp 504 AL KK is a high-quality aluminium clamping piece, specifically engineered for secure photovoltaic mounting on double standing seam roofs. Designed in collaboration with Rheinzink, this seam clamp is particularly suited for titanium zinc sheet roofing, offering a reliable and approved solution for solar installations.
With its precision-manufactured aluminium construction, this clamp ensures durability, structural integrity, and long-term resistance to environmental stress. It provides a stable and secure connection without penetrating the roof surface, making it an ideal choice for standing seam roofs where preservation of roofing material is essential.
Technical Specifications
| Feature | Specification |
|---|---|
| Brand | Schletter Solar |
| Product Type | Seam Clamp for Standing Seam Roofs |
| Model Number | 112001-010 |
| Material | Aluminium |
| Width | 35 mm |
| Height | 154 mm |
| Depth | 111 mm |
| Roof Compatibility | Double standing seam roofs made of titanium zinc sheet |
| Flanged Fold Dimensions | h = 11-13 mm, b1 = 4-6 mm, b2 = max. 3 mm |
| Maximum Profile Length | Approx. 3 m (without thermal separation) |
| Approval | Developed and approved by Rheinzink |
