Victron Energy Inverter RS 48/6000 230V Smart

Inverter RS Smart Solar 48/6000

The Inverter RS Smart Solar 48/6000 is a state-of-the-art off-grid solar inverter designed for applications requiring reliable and efficient AC power. With a powerful 48 V 6 kVA inverter and a 450 VDC 4 kWp PV input, this inverter is perfect for residential, commercial, and industrial off-grid solar energy systems. Combining cutting-edge technology with a lightweight and compact design, it ensures exceptional performance, versatility, and ease of use.

This innovative inverter integrates an inverter, a bi-directional DC-DC converter, and an MPPT solar charge controller, making it an all-in-one solution for managing your solar energy system. The inverter produces a high-quality pure sine wave, suitable for powering demanding appliances, while the bi-directional converter can charge the battery with excess solar power or supply energy from the battery when needed.

Key Features

• Powerful Inverter: 48V, 6 kVA with a high-quality pure sine wave output for powering sensitive appliances.
• MPPT Solar Charge Controller: Wide MPPT voltage range of 65 – 450 VDC with a 120 VDC PV startup voltage for efficient solar energy harvesting.
• Lightweight and Compact: Weighs only 11 kg thanks to high-frequency technology and a modern design.
• Quiet and Efficient: Low standby power, high efficiency (up to 96.5%), and very quiet operation.
• Display and Bluetooth Connectivity: View battery, inverter, and solar parameters on the display or via Bluetooth with the VictronConnect app.
• VE.Can and VE.Direct Ports: For system monitoring, data logging, and remote firmware updates via a GX device or GlobalLink 520.
• Built-in PV Isolator: Safely isolate parallel PV strings connected via MC4 plugs using the built-in isolator switch.
• Programmable Connections: Includes a relay, temperature sensor, voltage sensor, and a configurable remote input for Victron smallBMS.

Technical Specifications

• AC Output: 230 VAC ± 2%, 50 Hz ± 0.1%
• Continuous Output Power: 5300 W at 52 VDC (25°C), 4500 W (40°C), 3000 W (65°C)
• Peak Power: 9 kW for 3 seconds, 7 kW for 4 minutes
• MPPT Operating Voltage Range: 65 – 450 VDC
• Maximum Efficiency: 96.5% at 1 kW load
• Battery Voltage: 48 VDC
• Dimensions (HxWxD): 425 x 440 x 125 mm
• Weight: 11 kg
• Operating Temperature: -40 to +65°C (fan-assisted cooling)
• Protection Class: IP21
• Connections: VE.Can, VE.Direct, M8 battery terminals, MC4 PV input

This inverter supports parallel and 3-phase operation, with up to 12 parallel units supported and 4 units per phase in 3-phase setups. It also includes advanced protection features such as short-circuit, overload, and earth leakage detection for safe and reliable operation.

You can download the datasheet for the Victron Energy RS Smart Solar Inverter range here.
