SolaX - X1 Boost G4 3300w Single Phase Inverter (2 MPPT)
SolaX - X1 Boost G4 3300w Single Phase Inverter (2 MPPT)
Couldn't load pickup availability
SKU:SX-123316
SolaX X1 Boost G4 3300W 2MPPT with DC Switch & WiFi (SX-123316)
Experience unparalleled performance with the compact and lightweight SolaX X1 Boost G4 3300W Inverter. Designed to optimise solar energy conversion, this advanced inverter features dual MPPTs for superior tracking efficiency. Its wide power range, enhanced intelligence, and seamless integration with home EV chargers, heat pump solutions, and microgrids make it the perfect choice for modern energy systems. With real-time monitoring and intuitive configuration, the X1 Boost G4 ensures a smarter and more efficient solar experience.
Equipped with Global MPP scan and I-V curve diagnosis, this inverter enhances system reliability by identifying component issues early. The robust design, high conversion efficiency, and IP66 rating make it suitable for both residential and small commercial applications, providing long-term energy savings and performance stability.
Key Features:
- Maximum efficiency of 98%
- Dual MPPT for optimal energy harvesting
- Low start-up voltage for improved performance
- Compact and lightweight design
- IP66 rated for indoor and outdoor use
- 10-year warranty for long-term reliability
Technical Specifications:
| Specification | Details |
|---|---|
| Model | X1-3.3T-D(L)-G4 |
| Max. PV Array Input Power | 6,600 W |
| Max. PV Input Voltage | 600 V |
| Start-up Voltage | 50 V |
| MPP Tracker Voltage Range | 40 V – 560 V |
| Number of MPP Trackers | 2 |
| Max. PV Input Current | 12.5 A per MPPT |
| Nominal AC Output Power | 3300 W |
| Max. AC Output Apparent Power | 3600 VA |
| Nominal AC Voltage/Range | 220/230/240 V; 180 V – 280 V |
| Nominal AC Frequency/Range | 50/60 Hz; ±5 Hz |
| Power Factor Range | 0.8 leading – 0.8 lagging |
| Max. Efficiency | 98% |
| Ingress Protection | IP66 |
| Operating Temperature Range | -25°C to 60°C |
| Dimensions (W x H x D) | 404 x 274 x 146 mm |
| Weight | 11 kg |
| Communication Interfaces | USB/RS485/DRM; Optional: Meter/CT |
| Display | 2 x LED + LCD (16 x 2) / APP |
Download the datasheet for the SolaX X1 Boost G4 3300W Inverter here.
For technical support or additional information, reach out to us at hello@offgridrenewables.co.uk.
